Gladen GS12-Slim

Technical Data Gladen GS12-Slim

• Recommended volume (sealed):

  25-30 Liter

• DC resistance (Rdc):

  3,56 Ω (series)

• Nominal impedance (ZN):

  2x2 Ω

• Resonance frequency (Fs):

  26,5 Hz

• Voice coil diameter:

  2,5 inch

• Voice coil height:

  30 mm

• Mechanical Q factor (Qms):

  5,64

• Electrical Q factor (Qes):

  0,49

• Total Q factor (Qts):

  0,45

• Moving mass (md):

  183,6 g

• Effective piston area (sm):

  551,5 cm²

• Mechanical resistance (Rms):

  5,42 kg/s

• Compliance (Cms):

  0,197

• Force factor (BL):

  11,17 Tm

• Equivalent air volume (Vas):

  61,5 dm³

• SPL 2,83V/1m:

  89,02 dB

• External diameter:

  330 mm

• Installation diameter:

  305 mm

• Installation depth:

  100 mm
