Mono amplifier

Gladen Rcore 1|1200

1-channel amplifier
Class D technology
1-ohm stable
1210 watts

Overview GLaden Rcore 1|1200

The RC1|1200 is a high-performance mono amplifier designed for subwoofer applications, offering uncompromising control, stability and continuous power output. The Class D amplifier delivers high efficiency and precise reproduction of low frequencies, making it ideal for high-performance bass systems for everyday use.

Thanks to its high- and low-level inputs, the RC1/1200 can be integrated into OEM and aftermarket setups alike. Analogue controls allow for quick and intuitive adjustments to be made directly to the unit without the need for additional software.

Key features:

- Class-D mono power amplifier
- Stable operation at low impedances
- Variable low-pass filter for precise subwoofer connection
- Subsonic filter to protect the speaker
- Adjustable bass boost for targeted level adjustment
- RTC connection

Technical Data Gladen RC 1|1200

Output power:

Output power at 4 ohms:

430 Watts
Output power at 2 ohms:

690 Watts
Output power at 1 ohm:

1210 Watts

Data:

Input voltage:

0,4V-10V Highlevel | 0,2V-5V Lowlevel
Frequency range:

10-220Hz
Lowpassfilter:

40-220hz/ 24db/Oct
Subsonic:

20-50hz/ 24db/Oct
Bassboost:

-6 / 0 / +6db
Efficiency above all else:

> 80 %
Auto-On (just High Level):

Off-BTL
Operating voltage:

10-16 Volts
Start/Stop:

7,5Volt / 3 sec
External fuse:

80 A
Dimensions:

285 x 150 x 52 mm
Weight:

1150 gram

Download

Manual Gladen RCore 1|1200 (PDF)
