2 channal Plug&Play amplifier
Gladen EX-80C1
- 2 channel amplifier
- Class AB technology
- Up to 1 x 80 @ 1 ohm
Overview Gladen EX-80C1
The GLADEN EX80c1 is a compact, 1–2-channel amplifier specially developed for flexible expansion and retrofitting in vehicles. As part of the GLADEN EXtension series, it is ideal for installations requiring the amplification of individual speakers, additional channels or subwoofers.
The amplifier features automatic signal summation and high/low-level detection. This allows it to be easily connected to different signal sources. Both speaker outputs and RCA signals can be processed directly, eliminating the need for additional adapters or signal converters.
Thanks to its variable operating mode, the EX80c1 can operate in both stereo (2-channel) and mono modes. This makes it suitable for use with front or rear speakers, as well as compact subwoofers. The Class A/B power amplifier ensures controlled power and clean signal processing.
Due to its compact size, the EX80c1 can be integrated into confined spaces. It thus provides a functional solution for targeted system expansion without requiring a fundamental change to existing system concepts.
- 1–2 channel amplifier
- Class A/B
- High and low level input
- Automatic signal summation
- Stereo or mono operation.
Technical specifications Gladen EX-80C1
Power:
-
Output power at 4 ohms:
1 x 20 Watt
-
Output power at 2 ohms:
1 x 40 Watt
-
Output power at 1 ohms:
1 x 80 Watt
Datas:
-
input sensitivity:
0.35 V ÷ 12 V
-
Dimensions:
82 x 110 x 40 mm
-
Housing:
Black
