4 channel high quality amplifier

Mosconi One 130.4

Mosconi One 130.4 M

  • 4 channel amplifier
  • Class AB technology
  • Up to 4 x 175 Watts @ 2 Ohm
  • 12 V and 24 V version
  • Also available as molex version

Overview Mosconi One 130.4

The MOSCONI ONE 130.4 is a universal 4 channel high quality amplifier in Class AB technology. It is the ideal amplifier for speaker systems and/ or medium-sized subwoofers. The ONE 130.4 is designed as a double stereo amplifier, but can also be operated in three-/ or two-channel mode. This amplifier is powerful and thanks to the analog Full Mosfet-technology has outstanding sound characteristics.

The ONE 130.4 is available as a MOLEX version (ONE 130.4 M) or with a conventional screw terminal.

  • Remote volume control (optional)
  • G-HOC slot
  • Low level / high level input mode (via switch)
  • Auto Sense (only in High Level mode)
  • 24 Volt version for truck operation available

Technical Data Mosconi One 130.4

Output Power:

  • Output power @ 4Ω:

    4 x 130 Watts

  • Output power @ 2Ω:

    4 x 175 Watts

  • Bridged Output power @ 4Ω:

    2 x 350 Watts

Specifications:

  • Input sensitivity:

    0.35 V ÷ 16 V

  • Crossover:

    20 - 225 Hz / HIGH pass - LOW pass - OFF

  • Dimensions:

    310 x 200 x 50 mm

  • Weight:

    2,6 kg

Download

Datasheet Mosconi One 130.4 (24V) (PDF)
Manual Mosconi One 130.4 (PDF)
