6 channel high quality amplifier

Mosconi One 100.6

  • 6 channel amplifier
  • Class AB technology
  • Up to 6 x 120 Watts @ 2 Ohm

Overview Mosconi One 100.6

The MOSCONI ONE 100.6 is a universal 6 channel high quality amplifier in Class AB technology. It is the ideal amplifier for speaker systems in combination with efficient subwoofers. The ONE 100.6 is equipped with a switchable FSA function. The FSA (Front Stage Adjuster) is based on an adjustable phase shift in a defined frequency range, and improves the stage imaging of your front speakers. This amplifier plays powerfully and offers superior sound characteristics thanks to the analog Full Mosfet-technology.

  • Remote volume control (optional)
  • Low level / high level input mode (by switch)
  • FSA (FRONT section)
  • Phase shift (SUB section)
  • Auto sense (only in high level mode)

Technical Data Mosconi One 100.6

Output Power:

  • Output power @ 4Ω:

    6 x 100 Watts

  • Output power @ 2Ω:

    6 x 120 Watts

  • Output power @ 4Ω:

    4 x 95 Watts + 1 x 250 Watts BTL

  • Bridged Output power @ 4Ω:

    3 x 240 Watts


Specifications:

  • Input sensitivity:

    0.35 V - 16 V

  • Crossover channel 1 + 2:

    45 - 225 Hz – 12 dB/Oct - HP (ON-OFF)

  • Crossover channel 3 + 4:

    20 - 225 Hz – 12 dB/Oct - LP or HP (always ON)

  • Crossover channel 5 + 6:

    45 - 225 Hz – 12 dB/Oct - LP (ON-OFF)

  • Dimensions:

    310 x 200 x 50 mm

  • Weight:

    2,7 kg
