Digital Signal Processor

Mosconi DSP 6to8 Pro

  • 6-channel input
  • 8-channel output

Overview Mosconi DSP 6to8 Pro

  • 48 kHz / 24 bit High Resolution-Audio

Technical Data Mosconi DSP 6to8 Pro

Inputs:

  • 6 x RCA (Cinch), switchable high/low level with autosense

  • 1 x BT interface, (only compatible with BTM)

  • 2 of them freely selectable as prioritized auto-fade/aux

  • ATOM Mixer menu with dynamic preset switching and "trigger" control


Outputs:

  • 8 x RCA analog
  • 12 V remote-out / autosense at high level signal


Equalizer:

  • Fully parametric 30 band EQ, can also be used graphically, + 12 to - 12 dB, Q: 0.5 - 40

  • Fixed: Channels Front (1 - 4)

  • Assignable channels: 5 + 6 = front, rear 7 + 8 = sub, center, free


Filter:

  • 5 per channel freely configurable

  • Highpass, lowpass, shelf, notch, allpas, peak EQ

  • Slope 6 - 120 dB/oct, variable Q, time and level


Other:

  • Time correction 0 - 12 ms (0.020 ms steps)

  • Input delay (channels 1 - 6) for correction of run-time delayed factory systems

  • Phase shift 0 - 180°

  • Level adjustment outputs (0.5 - dB steps)

  • Mute function

  • 4 x preset memory (switching without sound interruption)

  • Dimensions: 150 x 125 x 40 mm (incl. mounting flange)
