Midrange Woofer

Gladen PRO 80

  • 2 x 110 / 70 Watts
  • 80 mm midrange woofer
  • 3 Ohm impedance
  • Push-pull drive
  • 25 mm voice coil

Overview GLADEN PRO 80

VOICES WITH NATURAL PRESENCE.

The PRO 80 is the dedicated midrange driver of the PRO series. It operates in the frequency range where voices and many instruments develop much of their tonal character.

Its tuning combines a natural, slightly full-bodied presentation with the control required for high resolution and clearly defined dynamic contrasts.

TECHNOLOGY & CONSTRUCTION

The mineral-coated paper cone combines the natural internal damping of paper with a reinforced surface structure.

The push-pull motor system and 25 mm voice coil are engineered to maintain controlled movement of the driver throughout its operating range.

FEATURES

  • 80 mm midrange driver
  • Mineral-coated paper cone
  • Push-pull motor system
  • 25 mm voice coil
  • 3 ohms
  • Made in Germany

System Application: Dedicated midrange driver for active 3-way systems


Technical Data GLADEN PRO 80

Specifications:

  • DC resistance (Rdc):

    2,6 Ω

  • Nominal impedance (ZN):

    3 Ω

  • Resonance frequency (fs):

    91,4 Hz

  • Voice coil diameter:

    25 mm

  • Cone:

    Paper (sand Coated)

  • Recommended high-pass frequency:

    > 320 Hz 12 dB/Oct
    > 270 Hz 18 dB/Oct
